High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar

Brand Name : Hongruntong Marine

Model Number : HM-FP29

Place Of Origin : China

Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS

MOQ : 1

Price : USD95 to USD990 Per Piece

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 3580 Pieces Per Month

Delivery Time : 5-6 Work Days

Packaging Details : Wooden Pallet, Wooden Case

Productname : Floating Pipeline

Operatingtemperaturerange : -40°C To 80°C

Lifespan : 20 To 30 Years

Installationmethod : Laid On Water Surface Or Submerged With Anchors

Applications : Oil And Gas Transport, Water Supply, Sewage Discharge

Safetyfeatures : Leak Detection Systems And Emergency Shut-off Valves

Environmentalimpact : Minimal, Designed To Reduce Seabed Disturbance

Material : NBR

Contact Now

UV Seawater Corrosion Resistant Floating Pipeline
Product Overview

Hongruntong Marine provides high-cost-performance Floating Pipelines (Floating Hoses) for global marine project contractors, balancing excellent performance with reasonable costs to optimize operational expenses. Our floating pipelines feature a scientific and simplified structure using high-quality, cost-effective raw materials while ensuring durability and reliability.

The integrated buoyancy design eliminates the need for additional floating accessories, reducing procurement and installation costs. The wear-resistant and corrosion-resistant rubber inner tube reduces replacement frequency, while the easy-to-clean outer cover further lowers long-term operational costs.

High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar
High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar
Key Features
  • Anti-Static & Flame-Retardant Properties: Integrated with specialized conductive materials and flame-retardant additives, meeting strict safety standards to prevent electrostatic discharge and ignition hazards
  • High Flow Efficiency: Smooth inner bore design minimizes friction loss and pressure drop, maximizing throughput of fluids, slurries, and dredged materials
  • Strict Manufacturing Tolerances: Computer-controlled extrusion and winding processes maintain precise tolerances for diameter, wall thickness, and length
  • Impact Resistance: Reinforced structure and durable outer cover effectively absorb shocks from floating debris, anchors, and underwater obstacles
Technical Applications
  • Offshore wind farm construction
  • Dredged material disposal
  • Chemical fluid conveyance in marine environments
Model Specifications
Model Dimensions (mm) Dimensions (inch) Working Pressure (bar) Working Pressure (psi) Safety Factor Bending Radius (mm) Weight (kg) Length (m)
HM-FP20 20 3/4" 16 230 6:1 80 0.8 40
HM-FP25 25 1" 16 230 6:1 100 1 40
HM-FP32 32 11/4" 16 230 6:1 125 1.3 40
HM-FP40 40 11/2" 16 230 6:1 140 1.5 40
HM-FP50 50 2" 16 230 6:1 180 2.5 40
HM-FP65 65 21/2" 16 230 6:1 200 3.3 40
HM-FP80 80 3" 16 230 6:1 260 4 40
HM-FP100 100 4" 16 230 6:1 380 6.8 40
HM-FP125 125 5" 16 230 6:1 440 9.2 40
HM-FP150 150 6" 16 230 6:1 500 13.2 40
HM-FP200 200 8" 16 230 6:1 750 18 40
HM-FP250 250 10" 16 230 6:1 900 26 25
*Note: Various sizes can be customized according to project requirements.
Application Benefits
  • Dual Chemical & Corrosion Protection: Premium synthetic rubber inner liner and outer cover provide unmatched resistance to corrosive marine chemicals
  • Integrated Anti-Static & Flame Retardancy: Conductive additives and flame-retardant materials eliminate electrostatic discharge risks and mitigate fire hazards
  • Leak-Proof Precision Sealing: Advanced flange connection systems with high-performance gaskets guarantee 100% leak-proof seals
  • Lightweight Offshore Deployment: Integrated buoyancy design simplifies offshore transportation, handling, and rapid deployment
  • Long-Term Environmental Durability: Engineered for prolonged service life in harsh marine environments, resisting ozone, saltwater corrosion, and temperature extremes
Product Images
High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar
High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar

High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar

High Flow Marine Floating Pipeline Flame Retardant Floating Hoses 16 Bar

Frequently Asked Questions
Does the floating pipeline reduce energy consumption for dredged material transfer?
Yes, its smooth inner bore design minimizes friction loss and pressure drop, maximizing slurry throughput and reducing the energy consumption of dredging pumping systems.
Can the pipeline resist damage from floating debris during dredged material disposal?
Definitely. Its reinforced structure and durable outer cover effectively absorb shocks from floating debris, anchors, and underwater obstacles, preventing punctures and tears.
Is the floating pipeline suitable for conveying corrosive chemical fluids in marine environments?
Yes, it is constructed with premium synthetic rubber inner liners and outer covers, providing unmatched resistance to acids, alkalis, solvents, and other corrosive marine chemicals.
Does the pipeline have anti-static and flame-retardant properties for chemical fluid conveyance?
Yes, it is integrated with conductive additives and flame-retardant materials, eliminating electrostatic discharge risks and mitigating fire hazards for volatile chemical fluids.
